How to reset airbag light

I think I have an airbag light come on. Its a light that looks like someone sitting down with a round ball in their lap in the tachometer. I think it went on after I honked the horn this morning. Could be coincedence. If it comes back on I know I have a problem. How do I reset it? I have way too many miles for warranty service. Thanks
usadaytrader is offline   Reply With Quote
Sponsored Links
Advertisement

Old 12-10-2008, 12:07 PM   #2 (permalink)
forget about "tsb's"

6shooter's Avatar

Join Date: Oct 2006
Location: PORTLAND , OR
Posts: 5,418
Gameroom cash: $110100
Thanks: 0
Thanked 13 Times in 13 Posts
iTrader Score: 0 reviews
View 6shooter's Photo Gallery
i wouldn't mess around with the air bag system, if it's on thqt means there is a problem. i would get it checked out.
6shooter is offline   Reply With Quote
Old 12-10-2008, 02:01 PM   #3 (permalink)
ASE Master Tech

Join Date: Sep 2008
Location: Walnut Creek, CA
Posts: 193
Thanks: 0
Thanked 0 Times in 0 Posts
iTrader Score: 0 reviews
View WCTacoTech's Photo Gallery
Without the proper scan tool you can't reset it.
WCTacoTech is offline   Reply With Quote
Old 12-10-2008, 03:47 PM   #4 (permalink)
One with the force

Join Date: Jul 2004
Location: Victorville, CA
Posts: 1,353
Thanks: 0
Thanked 21 Times in 19 Posts
iTrader Score: 0 reviews
View 91MR2quickNA's Photo Gallery
Quote:
Originally Posted by WCTacoTech View Post
Without the proper scan tool you can't reset it.
There's the old fashioned way, and it's listed in the factory Toyota repair manual if the scan tool does not remove the light.

Perhaps you've heard of "playing the drums?" You connect a service wire to terminals AB and TC in the 'DIAGNOSTIC' port on the engine harness. You know, the one we used to use for OBDI.

You then alternately ground (just use a strut nut or something) AB and TC in 1 second intervals. The timing needs to be right. It should start blinking at you. Do it until it clears. It's difficult.

We MR2 guys have had to do this to clear our air bag lights for years. Any work done near the dash (like installing a stereo) would set it off. It's still the same for OBDII when the scan tool fails.
__________________
Jason
2005 Tacoma D-Cab 4x4 Off-Road
1991 MR2 w/ ported 1MZFE (MZW20)
1991 MR2 N/A (SW21)

Last edited by 91MR2quickNA; 12-10-2008 at 03:49 PM.
91MR2quickNA is offline   Reply With Quote
Old 12-10-2008, 04:20 PM   #5 (permalink)
Stupid is stupid does

lotust's Avatar

Join Date: Oct 2003
Location: NY Long Island
Posts: 5,552
Thanks: 42
Thanked 2 Times in 2 Posts
iTrader Score: 3 reviews
View lotust's Photo Gallery
like 6shooter says. I would not mess with it. Do what you want though.
__________________

295/65/18 Goodyear Duratracs:2.5" lift in the front with 1" rear Block
JBA single exhaust:HID's W/Led's inside:Nfabs
E&G grill insert:ARE Z topper:Overhead DVD for my son:Front DVD for me
lotust is offline   Reply With Quote
Old 12-10-2008, 04:32 PM   #6 (permalink)
Official TN Member

Join Date: Oct 2005
Location: Cali
Posts: 299
Thanks: 2
Thanked 3 Times in 3 Posts
iTrader Score: 0 reviews
View usadaytrader's Photo Gallery
Light went off by itself. Thanks guys.
usadaytrader is offline   Reply With Quote
Old 12-11-2008, 10:59 AM   #7 (permalink)
Official TN Member

Join Date: Aug 2006
Location: La Cali
Posts: 617
Gameroom cash: $171250
Thanks: 5
Thanked 40 Times in 37 Posts
iTrader Score: 0 reviews
View integlikewhoa's Photo Gallery
The code is still stored in history and there is still a problem. I would have it checked out. Like others have said its a problem you want checked out, don't ignore it. Also it came on for a reason so to say theres no problem is a lie.
__________________
'06 Tacoma Double Cab 4x4, Auto , TRD-Off Road, Silver. BHL mod and removed emblems
Fabtech 6" lift W/Dirtlogic coilovers, 3" front spacer, 3" bodylift, 20" ProComp 5936 W/35" Toyo OpenCounty M/T tires, Camburg UCA's, longer SS brake lines.
integlikewhoa is offline   Reply With Quote
Old 12-11-2008, 11:15 AM   #8 (permalink)
ASE certified technician

Join Date: Dec 2008
Location: North Dallas
Posts: 28
Thanks: 0
Thanked 0 Times in 0 Posts
iTrader Score: 0 reviews
View Cody the Mechanic's Photo Gallery
You cannot reset an airbag light without fixing the problem. The system is made to report a problem the second it sees a problem. The only way to fix it would be to take it somewhere and have it diagnosed and the part that has gone bad, fixed. If it happened when you honked the horn, then it could be the spiral cable, and the steering angle sensor. or it could be something totally unrelated. Could be anything from a airbag ecu to a yaw rate sensor. simply "clearing the code" wont make it go away unless the problem somehow fixed itself. Which....i have seen happen without explaination. i know this happened with you...but i posting this as general info.
__________________
ASE/ Certified Toyota Tech in Dallas Area

Last edited by Cody the Mechanic; 12-11-2008 at 11:16 AM.
Cody the Mechanic is offline   Reply With Quote
Old 12-12-2008, 08:54 PM   #9 (permalink)
One with the force

Join Date: Jul 2004
Location: Victorville, CA
Posts: 1,353
Thanks: 0
Thanked 21 Times in 19 Posts
iTrader Score: 0 reviews
View 91MR2quickNA's Photo Gallery
Quote:
Originally Posted by integlikewhoa View Post
The code is still stored in history and there is still a problem. I would have it checked out. Like others have said its a problem you want checked out, don't ignore it. Also it came on for a reason so to say theres no problem is a lie.
Read below.

DTC Normal Source Voltage Drop
(no code is output, but the SRS light will stay ON)

CIRCUIT DESCRIPTION
The SRS is equipped with a voltage–increase circuit (DC–DC converter) in the airbag sensor assembly in case the source voltage drops. When the battery voltage drops, the voltage–increase circuit (DC–DC converter) functions to increase the voltage of the SRS to normal voltage. The diagnosis system malfunction display for this circuit is different from other circuits that is when the SRS warning light remains lit up and the DTC is a normal code, source voltage drop is indicated. Malfunction in this circuit is not recorded in the airbag sensor assembly, and when the source voltage returns to normal, the SRS warning light automatically goes off.

There is no other malfunction that would clear itself.
__________________
Jason
2005 Tacoma D-Cab 4x4 Off-Road
1991 MR2 w/ ported 1MZFE (MZW20)
1991 MR2 N/A (SW21)
91MR2quickNA is offline   Reply With Quote
Old 03-25-2009, 09:34 AM   #10 (permalink)
Official TN Member

tr7driver's Avatar

Join Date: Jul 2007
Location: Central Illinois
Posts: 259
Thanks: 21
Thanked 5 Times in 5 Posts
iTrader Score: 0 reviews
View tr7driver's Photo Gallery
Quote:
Originally Posted by 91MR2quickNA View Post
There's the old fashioned way, and it's listed in the factory Toyota repair manual if the scan tool does not remove the light.

Perhaps you've heard of "playing the drums?" You connect a service wire to terminals AB and TC in the 'DIAGNOSTIC' port on the engine harness. You know, the one we used to use for OBDI.
I'm trying to find this port on a 01 highlander V6 4wd. It is not above the rear timing belt cover on the air intake where I've seen it on other Toyotas. Any idea where I could find it?


Thanks
__________________
2001 Highlander V6 Limited 4wd
2005 Mustang GT Convertible
2014 Ford Fusion Hybrid
1979 Triumph TR7
tr7driver is offline   Reply With Quote
Old 03-25-2009, 11:15 AM   #11 (permalink)
Georgia

Jeddak's Avatar

Join Date: Jun 2007
Location: Robert's Union of Communist States
Posts: 1,175
Gameroom cash: $143695
Thanks: 11
Thanked 5 Times in 5 Posts
iTrader Score: 0 reviews
View Jeddak's Photo Gallery
Quote:
Originally Posted by tr7driver View Post
I'm trying to find this port on a 01 highlander V6 4wd. It is not above the rear timing belt cover on the air intake where I've seen it on other Toyotas. Any idea where I could find it?


Thanks
OBDI ports are always on the lower left under the dash, near the steering column. I never heard of them being in the engine compartment.
__________________
Impeach Chief Rat Roberts now!
Jeddak is offline   Reply With Quote
Old 11-23-2011, 03:02 PM   #12 (permalink)
New TN User

Join Date: Nov 2011
Location: Winston Salem, NC
Posts: 4
Thanks: 0
Thanked 0 Times in 0 Posts
iTrader Score: 0 reviews
View pormoonman's Photo Gallery
I'm trying to rest the air bag system for my 2005 Corolla. You mentioned "connect a service wire to terminals AB and TC in the 'DIAGNOSTIC' port on the engine harness. You know, the one we used to use for OBDI." I'm trying to locate this port under the hood without success. Can you point me in the right direction. Thanks.
