V8 engine swap

I just wondering if someone done V8 swap??
I have a 1986 Toyota pickup,22R engine and i want to swap V8 engine.
I know about v8 swap kit, where can i find it?
Any info, i will be glade.
supercharged3.0 is offline
Sponsored Links
Advertisement

#2 Old 01-29-2008, 08:52 AM
Not a Pre-runner

Twisted Sid's Avatar

Join Date: Dec 2003
Location: Apple Valley, Ca
Posts: 1,339
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 5 Post(s)
Thanks: 26
Thanked 72 Times in 60 Posts
iTrader Score: 2 reviews
Quote:
Originally Posted by supercharged3.0 View Post
I just wondering if someone done V8 swap??
I have a 1986 Toyota pickup,22R engine and i want to swap V8 engine.
I know about v8 swap kit, where can i find it?
Any info, i will be glade.
http://www.toyotanation.com/forum/search.php
Search by Key Word= V8 swap i
Search in Forum(s)= Search in Forum(s) 89-95Toyota Pickup/Hilux

'94 Pickup: Std Cab, 22RE, 5spd, 2wd
Front: Total Chaos Uniball Kit, Fox 8''Coilovers, Custom Engine Cage, Hannemann Fenders,
REAR: Deaver F67 Leafs, Fox 14''Shocks, Custom Bed Cage, Glassworks Bedsides, Tacoma E-locker Axle 4:88 31x10.5 BFG AT Tires

Last edited by Twisted Sid; 01-29-2008 at 06:19 PM.
Twisted Sid is offline
#3 Old 01-31-2008, 04:04 AM
Official TN Member

Join Date: Jan 2008
Location: Loa Angeles, CA
Posts: 65
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Thanks: 0
Thanked 0 Times in 0 Posts
iTrader Score: 0 reviews
(Thread Starter)
I found a really nice web site, where you can buy any parts for swapping a V8.
http://northwestoffroad.com/parts/engineadapters.html
supercharged3.0 is offline
#4 Old 02-02-2008, 12:55 PM
New TN User

Join Date: Feb 2008
Location: Sweden
Posts: 19
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Thanks: 0
Thanked 0 Times in 0 Posts
iTrader Score: 0 reviews
advanceadapters.com
I've baught a coplue of kits there and they work fine.
a Chevy 305 would do the trick...
Some mods to clutch, a special starter motor required.
huskyohilux is offline
#5 Old 02-14-2008, 06:25 PM
Official TN Member

Join Date: Jan 2008
Location: Loa Angeles, CA
Posts: 65
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Thanks: 0
Thanked 0 Times in 0 Posts
iTrader Score: 0 reviews
(Thread Starter)
Quote:
Originally Posted by huskyohilux View Post
advanceadapters.com
I've baught a coplue of kits there and they work fine.
a Chevy 305 would do the trick...
Some mods to clutch, a special starter motor required.
Did you do that, swap? How much you spent? What about transmission adapter? Will chevy 305 or 350 fit in to my tranny?
supercharged3.0 is offline
#6 Old 02-15-2008, 03:33 AM
New TN User

Join Date: Feb 2008
Location: Sweden
Posts: 19
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Thanks: 0
Thanked 0 Times in 0 Posts
iTrader Score: 0 reviews
You can do it two ways;
either you can keep your stock toyota 5 spd manual box and get a adapter between the engine and transmission or you can use a chevy th350 or 400 automatic and only use the toyota transfer case. That kit is a bit cheaper.
Any chevy small block from 262 to 400 cui will fit, most of my friends use the 305 which is an excellent engine (even that will burn the clutch if you aren´t carefull). A big block will also physically mount but is a bit tighter to squeeze in, especially if you want the radiator mounted in the front (some mount it on the bed, behind the cabin if you´re looking for a real potent offroader)
You will also need special engine mounts and a special oil pan if you don´t have the truck lifted, the front axle need some more clearence with a v8.
As said befor a special starter motor with a smaller nose cone is recommended because the adapter is cast with a smaller hole, or you can just take an angle grinder and make room for the stock chevy starter
You also need a flywheel for the clutch and either a special kit including a gm 10,5" clutch disc and pressure plate or the toyota OEM with mods on the flywheel (the pressure plate must be fitted and balanced on the flywheel and new holes must be drilled)
I´m not sure about the pricing since the shipping was a big part of our expenses, but you should manage to getaway below $1000 depending on which parts you´re choosing.
I don´t bulid the trucks myself, it´s actually some friends down in Tenerife (an island of the african west coast) I just import the parts since they don´t know any english. If you want any pictures, I´ve got a ton of them!
Good luck/ Andreas, Sweden
huskyohilux is offline
#7 Old 02-15-2008, 05:40 PM
Official TN Member

Join Date: Jan 2008
Location: Loa Angeles, CA
Posts: 65
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Thanks: 0
Thanked 0 Times in 0 Posts
iTrader Score: 0 reviews
(Thread Starter)
Wow!!! Thanx for info man! Yes, i want pictures, send them please on turboprobelx2006@yahoo.com

Basically, what i want to do is, i want to remove my stock 4cyl engine with auto transmission and i want to put some chevy V8 with manual tranny.
I do not want to use my auto tranny, because, i know it will not handle power from V8. Plus, i am gonna spend money for adapters, which is expensive.
So, what do you think, what kind of tranny should i bay, auto or manual?
About granding, welding.... do not be worry, i know how to do that.
Check out my truck here: 86-95 Toyota pickup Truck Topper Camper Shell Cap

Quote:
Originally Posted by huskyohilux View Post
You can do it two ways;
either you can keep your stock toyota 5 spd manual box and get a adapter between the engine and transmission or you can use a chevy th350 or 400 automatic and only use the toyota transfer case. That kit is a bit cheaper.
Any chevy small block from 262 to 400 cui will fit, most of my friends use the 305 which is an excellent engine (even that will burn the clutch if you arenīt carefull). A big block will also physically mount but is a bit tighter to squeeze in, especially if you want the radiator mounted in the front (some mount it on the bed, behind the cabin if youīre looking for a real potent offroader)
You will also need special engine mounts and a special oil pan if you donīt have the truck lifted, the front axle need some more clearence with a v8.
As said befor a special starter motor with a smaller nose cone is recommended because the adapter is cast with a smaller hole, or you can just take an angle grinder and make room for the stock chevy starter
You also need a flywheel for the clutch and either a special kit including a gm 10,5" clutch disc and pressure plate or the toyota OEM with mods on the flywheel (the pressure plate must be fitted and balanced on the flywheel and new holes must be drilled)
Iīm not sure about the pricing since the shipping was a big part of our expenses, but you should manage to getaway below $1000 depending on which parts youīre choosing.
I donīt bulid the trucks myself, itīs actually some friends down in Tenerife (an island of the african west coast) I just import the parts since they donīt know any english. If you want any pictures, Iīve got a ton of them!
Good luck/ Andreas, Sweden
supercharged3.0 is offline
#8 Old 02-15-2008, 05:54 PM
yota bomber

93 toyota's Avatar

Join Date: Aug 2006
Location: Rhode Island
Posts: 815
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Thanks: 0
Thanked 2 Times in 2 Posts
iTrader Score: 0 reviews
huskyohilux if you are ever bored post some of those pics on the forum


SHARE SHARE SHARE!!!!

-DREW


93 toyota 13 inches of lift and flipped
05 Cummins that rolls coal
93 toyota is offline
#9 Old 02-15-2008, 08:46 PM
DCM
One with the farce

Join Date: Apr 2005
Location: BC
Posts: 2,832
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 2 Post(s)
Thanks: 51
Thanked 168 Times in 148 Posts
iTrader Score: 0 reviews
I used a 350 and TH700R4 (because of the overdrive gear) when I did the swap in my '81.

I personally wouldn't bother with a 305 because a 350 is the same size and will produce more power.

'92 ST185 All trac turbo
'91 Cressida
'72 TE27

DCM is offline
#10 Old 02-16-2008, 07:15 AM
New TN User

Join Date: Feb 2008
Location: Sweden
Posts: 19
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Thanks: 0
Thanked 0 Times in 0 Posts
iTrader Score: 0 reviews
Just uploaded a couple of pictures in my gallery.
The big truck is my firends with a chevy 305, chevy axles, bedlock rims w/ 38" super swampers, rubicon bars, coil over rear suspension, teraflex and leaf springs in front, trail gear 4.70:1 reduction kit.
The white VW is my truck that I overhauled myself. The VW Taro trucks were sold in Sweden and were basically a Toyota Hilux pickup built in Germany, I think. Now it´s a black Toyota! No rust, aluminium bed, BFG A/T 31", overhauled 22r-e.

Last edited by huskyohilux; 02-16-2008 at 04:04 PM.
huskyohilux is offline
#11 Old 03-01-2008, 12:47 AM
Buck Up or Doe Out (TM)

colvilletacoma's Avatar

Join Date: Jan 2008
Location: Central Washington
Posts: 1,539
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Thanks: 1
Thanked 1 Time in 1 Post
iTrader Score: 0 reviews
I got the swap in but I cant find a good radiator that I can get for semi-cheap. The northwest site doesnt have them to purchase on their site. I have found other sites but I would be paying around 400 bucks. If someone knows a site or where I could get one for cheaper please let me know. Also go to this site if you want to see my toyota with the V8 in it (its a video)
http://www.youtube.com/watch?v=a7liVuc4BNI
colvilletacoma is offline
#12 Old 08-01-2009, 04:41 PM
Official TN Member

Fergifruitchew's Avatar

Join Date: Sep 2008
Location: Nanton, Alberta
Posts: 324
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Thanks: 3
Thanked 3 Times in 3 Posts
iTrader Score: 0 reviews
in my 92 toyota pickup 2wd im putting a chevy 305 and possibly the auto transmission with it aswell if i cannot find a bellhousing adapter to keep my toyota manual trans... it would make things so much easier to keep my transmission in it. then i dont have to worry about friggin around with linkages and such. just put the slave cylinder on the bellhousing and its good to go.
Fergifruitchew is offline
#13 Old 05-21-2010, 01:06 PM
New TN User

Join Date: May 2010
Location: Eugene, Oregon
Posts: 3
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Thanks: 0
Thanked 0 Times in 0 Posts
iTrader Score: 0 reviews
Quote:
Originally Posted by colvilletacoma View Post
I got the swap in but I cant find a good radiator that I can get for semi-cheap. The northwest site doesnt have them to purchase on their site. I have found other sites but I would be paying around 400 bucks. If someone knows a site or where I could get one for cheaper please let me know. Also go to this site if you want to see my toyota with the V8 in it (its a video)
http://www.youtube.com/watch?v=a7liVuc4BNI

dude go on jegs.com! they have a bitchin aluminum radiator that i used in my sbc swap and it fits beautifully! and the cool part is...its only 160 bones! heres the jegs part # 555-52005 $159.00
Blue_Chevota is offline
#14 Old 05-21-2010, 01:14 PM
yota bomber

93 toyota's Avatar

Join Date: Aug 2006
Location: Rhode Island
Posts: 815
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Thanks: 0
Thanked 2 Times in 2 Posts
iTrader Score: 0 reviews
what up throw back thread of the year....


93 toyota 13 inches of lift and flipped
05 Cummins that rolls coal
93 toyota is offline
#15 Old 06-03-2010, 08:04 PM
New TN User

Join Date: Aug 2009
Location: Cape Girardeau Missouri
Posts: 10
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Thanks: 0
Thanked 0 Times in 0 Posts
iTrader Score: 0 reviews
Quote:
Originally Posted by Blue_Chevota View Post
dude go on jegs.com! they have a bitchin aluminum radiator that i used in my sbc swap and it fits beautifully! and the cool part is...its only 160 bones! heres the jegs part # 555-52005 $159.00
How well is this radiator working? My swapped truck developed a hole and I order'd this one

2006 Trailblazer 4x4...wifes
2002 Camaro SS....knockin on the 10sec door
1989 4x4 ext cab yota...new toy/daily driver
SuperSlow02 is offline
