2005+ Tacoma Modification DIY Articles

[cam2Xrunner]

Thanks to all who have contributed to this thread. These are some great mods for the '05+ Tacoma. I'll leave this thread open, so if anyone has a link to other good DIY articles, please post them here and I will add them to this first post.

DISCLAIMER: Do at your own risk. Toyotanation will not be held responsible for any damage to vehicle or bodily harm when performing these modifications, or any Voidage of certain parts of your warranty.

Exterior Mods:
UCA Install-toku58
ABS Clip for UCA's-6shooter
Fog lights Always On -Pb
Detailed Fog Light Always On - SWTRDSPORT
Add Bed Lights & Backup Lights -Pb
DayTime Running Lights Mod -toku58
DayTime Running light ON/OFF-HookEm
Clear Corner Headlamps -Blangkang
Black Headlamp Housing -05XRunner
Black Emblem -NorCal Tacoma
Swapping black door handles for color matched handles -57HotrodVW
S2000 Projector & HID Retrofit -eyevan
Louder Horn -kinewave
Locks for the bed storage doors -oconnor
Combination locks for the bed storage doors -padlinout
Tailgate Security-Pop & lock and hose clamp mod -Hughes500Pilot
Extra Bed Rings -MrGrimm
Tailgate Alarm -JackSnodGrass
Tailgate Storage -Hughes500Pilot
Alternative Bike Mounts -ThunderStruck1
Trailer Harness Relocation -MrGrimm
Painting Wheels -Phi Kai
Diff Lock Anytime
Power lock "BEEP"-dbbd1
LOCKER MOD Alternative-dbbd1
Bumper plugs -Rhino8541
Fog lights behind grill-ilovetacos
Under hood lights- mjonags32
Bed lights-mjonags32
Bed Speakers-majonags32
Installing blocks to lift your rear-lotust
Side marker as turn signal-PB
Light bar and lights install-G-forcexl
Custom T O Y O T A grill emblem- toku58
Fog Lights "a la DTRL mode"- caribe_makaira
Satoshi Grill mod-lwyattl
How To Debadge and Rebadge"- juddemt
How To: Install A Power Pop&Lock-griffin407c

Interior Mods:
Installing Complete Sound system -Cam2Xrunner
Change the color of the instrument cluster -jotaro
Change the color of the stock radio lights -slvrAZtaco
Illuminated 4x4 Switch
Get rid of the open door buzzer -Cam2Xrunner
Add OEM Cruise Control -mhadden
Add OEM Intermittent Wiper Switch - Dcaplan
Boost Gauge Install xrobber
Shift light Install-Blangkang
Make an inline fuse quick & cheap -Pb
Map Lights come ON w/ Dome lights -Pb
Add In-Cab 110 AC Outlets -Pb
Cig Outlet always on - cheg
Add HomeLink/AutoDimming Mirror -Pb2theMax
Auto Dimming Mirror Install -SandMan-
ScanGauge Overhead Console Mod -Pb
Tire Pressure Monitor disable -ncpaladin
Cathode Footwell Lights-GrantGrant
How to remove the door panels to gain access to replace speakers -Cam2Xrunner
How to remove radio & how to install iPod2car
More info on ipod2Car -kpagel
Auxilary Input Install for factory CD player -Hughes500Pilot
USASpec DF-TOY Install for Aux Inputs to Stock Stereo -MrSharkey
Hardwiring Radar Detector -nicoj1222
Add Cabin Air Filter in '05 Taco -MikeX
Front window rattle fix -Cam2Xrunner
Programming Keyless Entry
Disabling the seatbelt alarm -TRDtoy79
Steering control color change -slvrAZtaco
Heated Seats Mod- Janster
Door Arm rest mod-menacekustoms
FJ Cruiser Switch Bezel Mod.-griffin407c


INTERIOR ISSUES
A.C. FAN TICKING -eyedoc

Performance Mods:
Toytec lift install -SMTRDSPORT
Tacoma 4.0 Exhaust FAQ -jubrown57
B&M 70255 Auto Transmission cooler install -Lotust
Hayden 678 Auto Transmission cooler install -oxnard111
Removing Secondary Air Filter -HILLCLIMBER
Clutch fan to Electric Fan -Pb
OffRoad Diff breather mod
Airbox Mod -55Reasons
Short Throw Clutch Pedal -Sonny
Useful info on modding the Sport Hood Scoop -Pb
Custom intake that could be combined with the Hood Scoop Mod -05XRunner
AEM/K&N Intake Hybrid -Boone
Diff Breather
Differential Breather mod "For Dummies"-Neubs
Information on lifts for 05+ Tacoma-toku58
MAF Calibrator MAP sharing-wjdunn3
Alignment 3" lift and UCA's-toku58
5100's install-luka



Maintenance:
Lubing diffs -Screeber
Lubing diffs -lotust
HEADLIGHT ADJUSTMENT
Reset Maint Req. light!-toku58



Misc. Issues:
-Engine Tapping noise

Tech Section at CutomTacos.com

[toku58]

Here is a DIY for the installation of the factory DTRL.
Part # 82241-04030 and # 81980-35020 Relay and jumper.

Here are the tool I used.


start by removing the rocker panel cover. Just pull up it is held on with clips.


Then remove the Foot pad; this is also held by clips; just pull:


There is a small plastic nut which needs to be removed:


Remove the kick panel by pulling it towards the back it is held on by 2 clips.


Then remove the 2-10 mm. bolts from the lower panel. Then pull out the little storage tray on the right side. (Just pull straight back) It is held on with clips.


Then pull the lower panel out. It is held on with the 2-10mm bolts (Which you removed in the previous step) and 3 clips which can be seen in the photo. Remember to remove the wire harnesses and the hood release.


Now remove the 3-10mm bolts that hold on the fuse box. Remove any wire harnesses that impede you from pulling the fuse box out. For me it was the 3 on the front left & one on the rear top portion. Use a needle nose to remove the clip without damage.


Now tilt the fuse box outwards and you will see the original relay. A square Tan relay.


Remove that and the gray plug that is located at the bottom of the rear of the fuse block. Below the flasher relay.


SORRY! The picture below is kind of confusing because the gray Jumper plug is already in the slot for the flasher!


Here is a picture of the 2 parts that you need to remove.


Now you need to assemble the new jumper and the new relay.




Now plug the gray end of the jumper into the slot where the old relay was located and the white plug into the slot where the gray blank plug was located. (This is how it should look when your done)


Now clip the new relay on to the holder which is located on the side of the fuse block near the steering:


And secure the wire with the clip that came on the jumper to the hole located on the back of the fuse block.

When you are done it should look like it came from the factory that way.

Now simply revers the process to put your panels back together and you are done!! DTRL work exactly like the factory install!!
If you have any questions please fell free to ask!!
Good luck!!
This is what you end up with:



Just like it came from the factory with them!

[jacksnodgrass]

I did this mod a while back.

http://www.toyotanation.com/forum/t145051.html

I think it might be usefull for this thread.

jack

[mundvi]

A floor waterproof
This tricks is adress to peaple who knows winter and who wants to keep their vehicule for the long time.
First, we have to empty the cab.

expand


expand


expand


and go under the carpet

expand


After that, we have to greace the floor on all the surface with white greace (no smell).

expand


Then put a wrap over the greace.

expand


Put back the cab.

expand


Now you got a floor that won't rusted. If you want to keep your vehicule for a long time and you don't want to look like the flinstones, it's a really good trick.

[mundvi]

Tonneau cover use full
For what I'm doing, I need acces fast and complete. Things that I transport doesn't allow me to have a close boxe in glass fibre. So I buy a "flexible tonneau cover".

expand


The bed extender is useful open or close for me. Put to have acces, I always had to "unsnape" and snap again. Very often in winter, is not easy to do.
So i made a system efficient and fast.

expand


expand


expand


expand


I installed a door latch on the back of the racking

expand


expand


I cut the racking and I made a double hinge.

expand


I re-enforce the cloth because I didn't wanted it to break.

expand


To be abble to keep the last rail of support, I separed the top lock in "C" and I screw on the racking.

expand


Now a have a fast acces to the back section and I can also I acces to all the space without losing my back vision.

expand

[bluzharp]

I have disabled the DRL's on my '05. I traded it in on an '06 and kept my modified flasher relay so I wouldn't have to redo it. It is not a difficult mod but a bit complicated. You have to remove the signal from the body ECU that decides whether they should be on or not, and then feed a signal to the flasher all the time to keep them off. I did it by removing a pin on the connector in the flasher relay and soldering a jumper down to digital signal in to disable them. It is the correct way to accomplish this without backfeeding the computer or running external wires. You could also just cut the wire and run the jumper outside the relay box if you are not comfortable soldering and desoldering on a circuit board.

I don't have a writeup but I will try to put it together. It is a great mod in my opinion, I hate those dang DRL's. If I want to run lights, I will just turn them on, I don't need the things on all the time.

NOTE: this is for the flasher marked >PPE+PS< below the connector. If you have DRL's in the US, you probably have this flasher.

METHOD 1:

1- remove the guts from the flasher box on the side of the body ECU under the dash, left of the steering column. I never figured out how to get the whole box off but you can snap the guts out from the cover and slide the board out. (it is a bit of a pain because there isn't a lot of room)

2- pull the plastic pin retainer out from the back of the connector and separate the board from the plastic connector.

3- remove (desolder) pin 12 from the circuit board. This is the signal coming in that turns off the lights. This is the pin that the green/red wire connects to.

4- Solder a jumper from pin 1 (12v when ign on) to the spot where pin 12 was. This is the pin that the pink wire connects to.

5- put everything back together and enjoy it.

METHOD 2:

If you wanted to do it externally, cut the green wire with the red trace on the plug to the flasher and connect it to the pink wire. You could use a scotchlock to connect the green/red wire to the pink wire. The pink wire is the 12 volt wire when the ignition is on. Be sure to feed the wire going into the flasher, not the side going to the ECU. I'm not sure if it would hurt anything, but I chose not to backfeed the computer. Put a piece of black tape over the end of the cut green/red wire coming from the body ECU.

Do this at your own risk. I used the factory wiring diagrams to come up with this mod. Check them for yourself to be sure that you know what you are doing or that I haven't made a mistake writing this up. I did this over 18 months ago, I have run it on 2 different trucks with no problems at all. I just rechecked the diagram while writing this so I'm fairly sure it is correct.

[Pb]

I just organized all the links. Let me know if you find any problems with any of the links.

[MrGrimm]

Anybody know where the Diff breather mod DIY went?

[Pb]

Originally Posted by MrGrimm

Anybody know where the Diff breather mod DIY went?

It's up there ^. Check the Perfomance Mods section.

[blacked out toy]

black hl mod........ when you put your lights in the oven do you put something down under them???are they hot as hell when you get them out ??? should i wear gloves of some sort??? kinda freaked out about doing this but im going to try it anyways...

[Pb]

Turn off the oven before you put the lights in there. You just use the radiating heat that's left in the oven. Don't cook the lights. Set the headlight on cardboard.

Just read the Black Headlight Mod thread. It will answer your questions, several times.
